海康工业相机拥有CE/CA/CH/CB/GL/CS多个系列，覆盖30万到1.51亿像素，包括GigE/10GigE/USB3.0/Camera Link/CoaXPress全系列接口，采用高品质的成像芯片，拥有十分出色的图像质量。
海康威视面阵相机提供高质量图像和出众的性价比。
从工厂自动化和智能交通监控系统(ITS)到零售、医疗和生命科学，无论在哪个领域，海康威视面阵相机都可以满您的应用需求。我们有黑白面阵工业相机、彩色工业相机、大靶面工业相机、高速工业相机等、可替换巴斯勒相机、宝盟相机、映美精相机、工业相机价格优惠、欢迎从我们产品线中挑选一款适合您应用的相机！
面阵工业相机：实现的是像素矩阵拍摄。工业相机拍摄的图像中，表现图像细节不是由像素多少决定的，是由分辨率决定的。分辨率是由选择的镜头焦距决定的，同一种相机，选用不同焦距的镜头，分辨率就不同。 像素的多少不决定图像的分辨率（清晰度），那么大像素相机有何好处呢？答案只有一个：减少拍摄次数，提高测试速度。面阵相机可以获取二维图像信息，测量图像直观。
面阵相机：应用面较广，如面积、形状、尺寸、位置，甚至温度等的测量。
面阵相机缺点：像元总数多，而每行的像元数一般较线阵少，帧幅率受到限制，因此其应用面较广，如面积、形状、尺寸、位置，甚至温度等的测量。由于生产技术的制约，单个面阵的面积很难达到一般工业测量现场的需求。
CS系列工业面阵相机CU系列工业面阵相机CH系列工业面阵相机CE系列工业面阵相机
CA系列工业面阵相机CL系列工业线阵相机CB系列板级相机CI系列红外相机
海康面阵相机和工业镜头选型
已知：被检测物体大小为A*B,要求能够分辨小于C，工作距为D 解答：
1. 计算短边对应的像素数 E = B/C，相机长边和短边的像素数都要大于E；
2. 像元尺寸 = 物体短边尺寸B / 所选相机的短边像素数；
3. 放大倍率 = 所选相机芯片短边尺寸 / 相机短边的视野范围；
4. 可分辨的物体精度 = 像元尺寸 / 放大倍率 （判断是否小于C）；
5. 物镜的焦距 = 工作距离 / (1+1 / 放大倍率) 单位：mm；
6. 像面的分辨率要大于 1 / (2*0.1*放大倍率) 单位：lpmm ；
海康CE/CA/CH/CB/GL/CS系列订货型号：
MV-CA003-20GC MV-CA003-21UC MV-CA004-10GC MV-CA004- 10GM MV-CA004- 10UC MV-CA004- 10UM MV-CA013-20GC MV-CA013- 20GM MV-CA013-21UC MV-CA013-21UM MV-CA013-A0GC MV-CA013-A0GM MV-CA013-A0UC MV-CA013-A0UM MV-CA016-10GC MV-CA016-10GM MV-CA016-10UC MV-CA016- 10UM MV-CA017-10GC MV-CA017- 10GM MV-CE013-80GC MV-CE013-80GM MV-CE013-80UM MV-CE050-30UC MV-CE050-31GC MV-CE100-30GC MV-CE120-10UC MV-CE120-10UM MV-CE200-10UM . MV-CE200-11UC MV-CE200-11UM . MV-CH040-A0CM MV-CH050-10CC MV-CH050-10CM MV-CH050-10UC MV-CH050-10UM MV-CH050-10UP MV-CH050-60UC MV-CH050-60UM MV-CH050-90XC-C -NN MV-CH250-20XC-M58S-NN MV-CH250-21GC-F-NF MV-CH250-21GC-M58S-NF MV-CH250-25TC- F-NF MV-CH250-25TC-M58S-NF MV-CH250-60TM-M58S-NF MV-CH250-90GC MV-CH250-90GM MV-CH250-90GN MV-CH250-90TC-C-NF MV-CH250-90TC-M58S-NF MV-CH250-90TM-C-NF MV-CH250-90TM-M58S-NF MV-CH250-90TN-M58S-NF MV-CH250-90UC MV-CH250-90UM MV-CH250-90UN MV-CH250-90VC MV-CH250-90VM MV-CH250-90XC-C-NN MV-CS050-10GM-PRO MV-CS050-10UC MV-CS050-10UM MV-CS050-20GC MV-CS050-20GM MV-CS050-60GC MV-CS050-60GM MV-CS050-60UC MV-CS050-60UM . MV-CS050-90GC MV-CS050-90GM MV-CS060-10GC MV-CS060-10GC-PRO MV-CS060-10GM MV-CS060-10GM-PRO MV-CS060-10UC-PRO MV-CS060-10UM-PRO MV-CS200-10GC MV-CS200-10GM MV-CS200-10UC MV-CU200-20GM(NPOE) MV-CZGHL-5GC MV-CZGHL-5GM MV-CZGL-20GC MV-CZGL-20GM BT-IS200-10GC BT-IS200-10GH HIK-BBK500F MV-120C-EDU MV-HY2500-00W-BCN MV-HY5000-00W-CMN MV-HY6500-00W-BFN MV-HY6500-00W-HFN MV-ZXHC012-CC MV-ZXHC012-CM MVGL-AC128G-201UC MVGL-AC128G-201UM MVGL-AC128G-91GC MVGL-AC128G-91GM MVGL-AC144G-249UC MVGL-AC410G-9GM MVGL-AC410G-9XGC MVGL-AC410G-9XGM MVGL-AC479G-27UM MVGL-AC479G-8GC MVGL-AC479G-8GM MVGL-AC512G-14UC MVGL-AC512G-14UM MVGL-AC512G-14UN MVGL-AC512G-30UC MVGL-AC512G-30UM MVGL-AC547R-19UC MVGL-AC547R-19UM |
MV-CA020-10GC MV-CA020-10GM MV-CA020-10UC MV-CA020-10UM MV-CA023-10GC MV-CA023-10GM MV-CA023-10UC MV-CA023-10UM MV-CA032-10GC MV-CA032-10GM MV-CA050-20GC MV-CA050-20GM MV-CA050-20UM MV-CB004-10GC-C MV-CB004-10GC-S MV-CB004-10GM-C MV-CB004-10GM-S MV-CB004-10GM-S-W MV-CB013-A0UC-C MV-CB013-A0UC-S MV-CH050-90XM-C-NN MV-CH089-10GC MV-CH089-10GC(EoL) MV-CH089-10GM MV-CH089-10GM(EoL) MV-CH089-10UC MV-CH089-10UM MV-CH100-60GC MV-CH100-60GM MV-CH100-60UC MV-CH100-60UM MV-CH1010-10CC-M72-NF MV-CH1010-10CC-M72-TF MV-CH1010-10CM-M72-NF MV-CH1010-10CM-M72-TF MV-CH1030-90TC- M58S-NN MV-CH1030-90TM-M58S-NN MV-CH120-10CC MV-CH120-10CM MV-CH120-10GC MV-CH250-90XM-C-NN MV-CH250-90YC-C-NN V2 MV-CH250-90YC-M58S-NN V2 MV-CH250-90YM-C-NN V2 MV-CH250-90YM-M58S-NN V2 MV-CH250-91TM-C-NF MV-CH310-10GC-F-NF MV-CH310-10GC-M58S-NF MV-CH310-10GM-F-NF MV-CH310-10GM-M58S-NF MV-CH310-10TC-M58S-NN MV-CH310-10TM-M58S-NN MV-CH500-90TC-M58S-NF MV-CH500-90TM-F-NF MV-CH500-90TM-M58S-NF MV-CH6040-10XM-M72-NF MV-CH650-90TC-F-NF MV-CH650-90TC-M58S-NF MV-CH650-90TM-F-NF MV-CH650-90TM-M58S -NF MV-CS200-10UM MV-CU004-10GC MV-CU004-10GC(NPOE) MV-CU004-10GM MV-CU004-10GM(NPOE) MV-CU013-80GC MV-CU013-80GC(NPOE) MV-CU013-80GM MV-CU013-80GM(NPOE) MV-CU013-80UC MV-CU013-80UM MV-CU013-A0GC MV-CU013-A0GC(NPOE) MV-CU013-A0GM MV-CU013-A0GM(NPOE) MV-CU013-A0UC MV-CU013-A0UM MV-CU016-10GC MV-CU016-10GC(NPOE) MV-CU020-19GC MVGL-AC144G-249UM MVGL-AC160G- 53GC MVGL-AC160G- 53GM MVGL-AC162G-60GC MVGL-AC162G-60GM MVGL-AC192G-40UC MVGL-AC192G-40UM MVGL-AC192G-41GC MVGL-AC192G-41GM MVGL-AC192R-56GC MVGL-AC192R- 56GM MVGL-AC194G-132UM MVGL-AC205G-30GC MVGL-AC205G-30GM MVGL-AC205G-49GC MVGL-AC205G-49GM MVGL-AC205G-90UC MVGL-AC205G-90UM MVGL-AC245G-23GC MVGL-AC245G-23GM |
MV-CB013-A0UM-B MV-CB013-A0UM-C MV-CB013-A0UM-S MV-CB013-A0UMM-C MV-CB016-10GC-C MV-CB016-10GC-S MV-CB016-10GC- S-W MV-CB016-10GM-C MV-CB016-10GM-M-W MV-CB016-10GM-S MV-CB016-10GM-S-W MV-CB016-10GM-S-W(POE) MV-CB016-10UC-B MV-CB016-10UC-C MV-CB016-10UC-S . MV-CB016-10UM-B MV-CB016-10UM-C MV-CB016-10UM-S MV-CB050-11UC-C MV-CB060-10GC-C MV-CH120-10GC(EoL) MV-CH120-10GM MV-CH120-10GM(EoL) MV-CH120-10UC MV-CH120-10UC(EoL) MV-CH120-10UM MV-CH120-10UM(EoL) MV-CH120-11CM MV-CH120-11UC MV-CH120-11UM MV-CH120-15TC-M58S-NF MV-CH120-15TM-M58S-NF MV-CH120-20GC MV-CH120-20GM MV-CH120-20UC MV-CH120-20UM MV-CH120-40XM-M58S-NN MV-CH120-60GC MV-CH120-60GM MV-CH120-60UC MV-CH650-90XC-M58S-NF MV-CH650-90XM-F-NF MV-CH650-90XM-M58S-NF MV-CH650-90YC-M58S -NN MV-CH650-90YM-M58S-NN MV-CH650-90YM-M58S-NN V2 MV-CI003-GL-N15 MV-CI003-GL-N25 MV-CI003-GL-N35 MV-CI003-GL-N6 MV-CI003-GL-T6 MV-CI013-GS-NN MV-CI013-GS-TF MV-CS004-10GC MV-CS004-10GM MV-CS004-10UC MV-CS004-10UM MV-CS004-11GC MV-CS004-11GM MV-CS013-60GN MV-CU020-19GC(850nm带通) MV-CU020-19GM MV-CU020-80GC MV-CU020-80GC(NPOE) MV-CU020-80GM MV-CU020-80GM(NPOE) MV-CU020-90GC MV-CU020-90GC(NPOE) MV-CU020-90GM MV-CU020-90GM(NPOE) MV-CU020-90UM MV-CU050-30GC MV-CU050-30GC(NPOE) MV-CU050-30GM MV-CU050-30GM(NPOE) MV-CU050-60UM MV-CU050-90GC MV-CU050-90GC(NPOE) MV-CU050-90GM MV-CU050-90GM(NPOE) MVGL-AC245G-24GC MVGL-AC245G- 24GM MVGL-AC245G-35GC MVGL-AC245G-35GM MVGL-AC245G-60BUC MVGL-AC245G-60BUM MVGL-AC245G-74UC MVGL-AC245G-74UM MVGL-AC245G-74UP MVGL-AC259G-20GC MVGL-AC259G- 20GM MVGL-AC259R-48UM MVGL-AC260G-21GC MVGL-AC260G-21GM MVGL-AC260G-59UC MVGL-AC260G-59UM MVGL-AC307R-19GC MVGL-AC307R-19GM MVGL-AC307R-59UC MVGL-AC307R- 59UM |
MV-CB060-10GC-S MV-CB060-10GC-S-W MV-CB060-10GM-C MV-CB060-10GM-M MV-CB060-10GM-S MV-CB060-10GM-S-W MV-CB060-10UC-B MV-CB060-10UC-C MV-CB060-10UC-S MV-CB060-10UM-B MV-CB060-10UM-C MV-CB060-10UM-S MV-CB120-10UC-B MV-CB120-10UC-C MV-CB120-10UC-S MV-CB120-10UM-B MV-CB120-10UM-C MV-CB120-10UM-S MV-CE013-50GC MV-CE013-50GM MV-CH120-60UM MV-CH120-90X2M-C-NN MV-CH120-90Y1C MV-CH120-90Y1M MV-CH140-60GC MV-CH140-60GM MV-CH140-60UM MV-CH1510-10FC-M72-TF MV-CH1510-10FM-M72-TF MV-CH1510- 10XC-M72-NF MV-CH1510-10XM-M72-NF MV-CH1510-11XC-M72-TF MV-CH1510-11XM-M72-TF MV-CH160-60GM MV-CH210-90Q2M-M58S-NF MV-CH210-90YC-M58S-NF MV-CH210-90YC-M58S-NN MV-CH210-90YM-M58S-NN MV-CH240- 10TM-C-NN MV-CH240-10TM-M58S-NN MV-CS016-10GC MV-CS016-10UC MV-CS016-10UM MV-CS016-11GM MV-CS020-10GC MV-CS020-10GM MV-CS020-10UC MV-CS020-10UM MV-CS023-10GC MV-CS023-10GM MV-CS028-10UM MV-CS032-10GC MV-CS032-10GM MV-CS032-60GC MV-CS032-60GM MV-CS040-A0UC MV-CS040-A0UM MV-CS050-10GC MV-CS050-10GC-PRO MV-CS050-10GM MV-CU050-90UC MV-CU050-90UM MV-CU060-10GC MV-CU060-10GC(NPOE) MV-CU060-10GM MV-CU060-10GM(NPOE) MV-CU060-10UC MV-CU060-10UM MV-CU060-60GC MV-CU060-60GM MV-CU060-60GM(NPOE) MV-CU120-10GC MV-CU120-10GC(NPOE) MV-CU120-10GM MV-CU120-10GM(NPOE) MV-CU120-10UC MV-CU120-10UM MV-CU200-20GC MV-CU200-20GC(NPOE) MV-CU200-20GM MVGL-AC320R-19GC MVGL-AC320R-19GM MVGL-AC400G-7GM MVGL-AC402R-9GC MVGL-AC402R-9GM MVGL-AC409G-68TC MVGL-AC409G-68TM MVGL-AC410G-11GC MVGL-AC410G-11GM MVGL-AC410G-28UC MVGL-AC410G-28UM MVGL-AC410G-30BUC MVGL-AC410G-30BUM MVGL-AC410G-30UC MVGL-AC410G-30UM MVGL-AC410G-36UC MVGL-AC410G-36UM MVGL-AC410G-9BGC MVGL-AC410G-9BGM MVGL-AC410G-9GC |
广州艾韦迅科技是海康威视HIKVISION旗下的海康机器人HikRobot海康智能读码器/工业相机经销商，供应海康扫描枪ID2000、ID3000、ID5000、ID6000等系列全部型号，海康威视HIKVISION读码器同时为 为电子、物流、FPD显示屏、半导体、汽车制造等领域提供专业机器视觉解决方案，海康工业读码器助力用户快速准确实现工业自动化。
